High-Performance COP32-90mm DTH Drill Bit for Water Well and Mining
Bit shank:COP32
Brand: Win Drill
Origine: China
Bit diameter: 90-110mm
Insert Button Shape: Spherical, ballistic, parabolic
Bit Faces: flat face, concave, convex
Packaging: Ply-wood box
Delivery Time: 5-30 days
Sample Order: Yes
OEM Service: Yes
Model:Â COP32-90mm
Premium Precision for Drilling Operations: The COP32-90mm DTH Drill Bit
In the demanding world of drilling, the COP32-90mm DTH Drill Bit stands out as a hallmark of engineering excellence, built to deliver precision and efficiency. Designed for the rigors of water well drilling, mining operations, and marble quarrying, this drill bit tackles the toughest conditions with ease. Each bit is meticulously crafted from the finest carbon steel, forged to perfection to ensure robustness where it matters most.
Versatile Design for Multiple Applications
This versatile bit is compatible with a range of 3″ DTH hammers and is designed to fit a variety of shank types including DHD3.5, IR3.5, MP35, MISSION30, and COP32. The range of bit diameters from 90 to 110mm allows for targeted drilling, accommodating a wide spectrum of borehole sizes with precision. Whether you’re boring through solid rock or softer substrates, the COP32-90mm DTH Drill Bit offers a tailored experience for optimal results.
Tungsten Carbide — The Material of Choice
Featuring a Tungsten Carbide construction, the COP32-90mm Drill Bit provides exceptional wear resistance, ensuring longevity and consistent performance under challenging conditions. The choice of material reflects a commitment to quality and durability, giving drillers the confidence to push the limits of their equipment.
Customizable for Specialized Drilling Needs
Understanding that drilling requirements can vary greatly, this bit offers customizable options to suit specific project needs. Its bit face designs, including center drop, flat, convex, and concave, as well as a range of button shapes from spherical to ballistic and parabolic, are selected to optimize drilling for the specific rock formation at hand.
Win Drill COP32 Series DTH Button Bit Specifications
| Bit Diameter | Part No. | No. x Button diameter (mm) | Weight | |||
| Gauge | Front Buttons | Â | ||||
| (mm) | buttons | Flat | Convex | Concave | (kg) | |
| Φ90 | COP32-90CV6 | 6xΦ14 | 2xΦ12 | 2xΦ13 | / | 4.3 |
| Φ90 | COP32-90FF6 | 6xΦ14 | 4xΦ12 | / | / | 4.3 |
| Φ95 | COP32-95CV6 | 6xΦ14 | 2xΦ13 | 2xΦ13 | / | 4.4 |
| Φ100 | COP32-100CV6 | 6xΦ14 | 2xΦ13 | 3xΦ13 | / | 4.6 |
| Φ105 | COP32-105CV6 | 6xΦ14 | 2xΦ13 | 3xΦ13 | / | 4.8 |
| Φ105 | COP32-105FF8 | 8xΦ13 | 6xΦ12 | / | / | 4.8 |
- Extensively used in water well drilling to penetrate deep aquifers.
- Suitable for geological explorations where sample integrity is paramount.
- Ideal for mining operations requiring large-diameter blast holes.
- Effective in construction projects for foundation work and piling.
